FS32K116LFT0MFMR

The FS32K116LFT0MFMR is an ARM Microcontroller Unit (MCU) produced by NXP Semiconductors, featuring detailed specifications as follows:

Basic Parameters

• Manufacturer: NXP
• Product Type: ARM Microcontroller - MCU
• Series: S32K1xx
• Mounting Style: SMD/SMT
• Package/Case: QFN-32 (other package options include LQFP-48, depending on product model and version)

Core & Processor

• Cores: ARM Cortex M0+, ARM Cortex M4F
• Data Bus Width: 32 bit
• Maximum Clock Frequency: 48 MHz (some versions support up to 112 MHz, depending on operation mode)

Memory Capacity

• Program Memory Size: 128 kB (Flash Memory)
• Data RAM Size: 17 kB

Power Supply & Temperature

• Operating Voltage: 2.7 V to 5.5 V
• Minimum Operating Temperature: -40 °C
• Maximum Operating Temperature: +125 °C (note: some sources mention up to 105 °C in HSRUN mode and 150 °C in RUN mode, depending on specific application environments and modes)

Interfaces & Communication

• Interface Types: UART, SPI, I2C, I2S
• Number of I/O Ports: 28 I/O (the exact number may vary depending on the package)

Additional Features

• Watchdog Timer: Watchdog Timer
• Energy Management: Equipped with low-power Arm Cortex-M4F/M0+ cores and multiple Power Management Controllers (PMC), supporting various power modes such as HSRUN, RUN, STOP, VLPR, etc.
• Security Functions: Including Cryptographic Service Engine (CSEc), 128-bit Unique Identifier (ID), Error Correction Code (ECC) for Flash and SRAM memories, etc.
• Debugging Capabilities: Supports Serial Wire JTAG Debug Port (SWJ-DP), Debug Watchpoints and Trace (DWT), Instrumentation Trace Macrocell (ITM), etc.

Package Options

In addition to the QFN-32 package, the FS32K116LFT0MFMR may also be available in other package options such as LQFP-48, 64-pin LQFP, 100-pin LQFP, 100-pin MAPBGA, 144-pin LQFP, 176-pin LQFP, etc., depending on product models and market demands.

Please note: The above parameters may vary due to product versions, production batches, or specific application scenarios. For accurate information in practical applications, please refer to the specific product datasheet or contact the manufacturer.
