MP6515GL-Z

The MP6515GL-Z is an electronic component manufactured by Monolithic Power Systems (MPS), typically classified as a motor/motion/ignition controller and driver, specializing in driving brushed DC motors. Below are the detailed specifications and features of the MP6515GL-Z:

Basic Information

• Manufacturer: Monolithic Power Systems (MPS)
• Product Model: MP6515GL-Z
• Product Type: Motor Driver/Controller
• Package Type: 20-QFN (also known as 20-TFQFN Exposed Pad), with specific dimensions of 3x4mm

Electrical Characteristics

• Operating Supply Voltage: 5.4V to 35V
• Voltage-Load: Maximum 40V
• Output Current: 2.8A
• Operating Supply Current: 1.5mA
• Power Dissipation: 2.6W

Operating Environment

• Minimum Operating Temperature: -40°C
• Maximum Operating Temperature: +125°C

Mounting & Packaging

• Mounting Style: Surface Mount Device (SMD/SMT)
• Packaging Forms: May include Tape and Reel (TR) and Cut Tape (CT)

Functionality & Applications

• Function: Acts as a driver for brushed DC motors, offering either Half Bridge or H-Bridge (depending on the specific model) output configurations.
• Technology: Utilizes Power MOSFET technology for efficient power conversion capabilities.
• Applications: Suitable for a wide range of general-purpose applications requiring motor driving, such as automation, robotics, automotive electronics, and more.
