SN74LVC1G14DCKR Custom Integrated Circuit 1.65V High Precision For Computers

SN74LVC1G14DCKR is a single Schmitt trigger inverter developed by Texas Instruments (TI), featuring the following key specifications:

Basic Parameters:

• Component Type: Gate and Inverter
• Function: Inverter with Schmitt Trigger characteristics
• Number of Circuits: 1
• Logic Type: Inverting
• Supply Voltage Range: 1.65V to 5.5V
• Package: SC-70-5
• Manufacturer: Texas Instruments

Electrical Characteristics:

• Low Power Consumption: Maximum quiescent supply current of 1μA (typical)
• Output Drive Capability: Maximum output drive current of ±24mA at 3.3V
• Propagation Delay: Typical value ranges from 4.3ns to 4.6ns at 3.3V
• Input/Output Voltage Range:
  • Input Voltage Range: -0.5V to 7V
  • Output Voltage Range: -0.5V to VCC + 0.5V

Operating Conditions:

• Operating Temperature Range: -40°C to +125°C
• Latch-up Performance: Exceeds 100mA per JESD 78 Class II
• ESD Protection: Exceeds 2000V Human Body Model (A114-A) per JESD 22 and other standards

Additional Features:

• Ioff Support: Partial power-down mode operation, allowing the output to be disabled to prevent damaging currents flowing through the device during power-off
• Application Range: Widely used in signal processing, portable equipment, consumer electronics, computers and peripherals, audio devices, power management, communication and networking, wireless, and other fields

Package and Pins:

• Number of Pins: 5
• Pin Functions: Typically includes VCC (Power Positive), GND (Ground), A (Input), Y (Output), and possibly NC (No Connect) pin
