SN74LVC1G14DCKR

The SN74LVC1G14DCKR is a general-purpose logic gate chip produced by Texas Instruments (TI). Below is a detailed summary of its main characteristics and parameters:

Basic Information

• Brand: TI/Texas Instruments
• Manufacturer: Texas Instruments
• Product Category: Converter
• RoHS: Yes (indicating compliance with the European Union's directive on the restriction of the use of certain hazardous substances in electrical and electronic equipment)

Electrical Characteristics

• Maximum Supply Voltage: 5.5 V
• Minimum Supply Voltage: 1.65 V
• Operating Supply Voltage: 1.65 V to 5.5 V
• High-Level Output Current: -32 mA
• Low-Level Output Current: 32 mA
• Quiescent Current (Max): 10 µA (estimated based on reference articles, actual values may vary slightly from different sources)

Operating Environment

• Minimum Operating Temperature: -40°C
• Maximum Operating Temperature: +125°C
• Operating Temperature Range: -40°C to +125°C

Physical Characteristics

• Package/Case: SC70-5 (a surface-mount package also known as SOT-23-5 or TSSOP-5)
• Mounting Style: SMD/SMT (Surface-Mount Technology)
• Unit Weight: 20 mg

Functionality & Features

• Logic Type: Inverting (Inverter)
• Logic Family: 74LVC
• Function: Single Schmitt Trigger
• Input Type: Schmitt Trigger (with hysteresis characteristic, enhancing noise immunity)

Applications & Uses

The SN74LVC1G14DCKR chip, due to its low power consumption, wide supply voltage range, and Schmitt trigger capabilities, is widely used in electronic devices requiring digital signal processing, such as communication equipment, computer systems, industrial controls, and other fields.

Notes

• The displayed price of the product on the platform may vary due to promotions or changes based on purchase quantity or selected specifications.
• When users and merchants reach an agreement offline, the settlement price should be based on the offline agreement.

In conclusion, the SN74LVC1G14DCKR is a powerful and versatile general-purpose logic gate chip, particularly suitable for applications requiring low power consumption and a wide supply voltage range.
