ZF5-36-01-T-WT

Large Image : ZF5-36-01-T-WT

Product Details: Payment & Shipping Terms:

Description:	CONN FFC BOTTOM 36POS 0.50MM R/A

Contact Now

ZF5-36-01-T-WT

Description

Flat Flex Type ::	FFC	Contact Finish ::	Tin
Actuator Material ::	-	Product Category ::	FFC & FPC Connectors
Package ::	Tube	Mounting Type ::	Surface Mount, Right Angle
Features ::	Solder Retention, Zero Ion Force (ZIF)	FFC, FCB Thickness ::	0.30mm
Number Of Positions ::	36	Operating Temperature ::	-55°C ~ 105°C
Termination ::	Solder	Height Above Board ::	0.079" (2.00mm)
Manufacturer ::	Samtec Inc.	Material Flammability Rating ::	-
Housing Material ::	Liquid Crystal Polymer (LCP)	Connector/Contact Type ::	Contacts, Bottom
Min Qty ::	0	Voltage Rating ::	-
Locking Feature ::	Slide Lock	Pitch ::	0.020" (0.50mm)
Contact Material ::	Phosphor Bronze	Series ::	ZF5
Cable End Type ::	Straight	Product Status ::	Active

The ZF5-36-01-T-WT,from Samtec Inc.,is FFC & FPC Connectors.what we offer have competitive price in the global market,which are in original and new parts.If you would like to know more about the products or apply a lower price, please contact us through the “online chat” or send a quote to us!
